SHU050150050

Victron Smartshunt 500A - 50Mv - Battery Monitor Via Bluetooth

This product is on order with our supplier (if no add to cart button is available, then we are not confident of the suppliers delivery date)

This is the cheapest way to get quality information on your batteries and state of charge - you just need the Victron Smart Connect app on your phone.

  • Ideal if you don't need a physical display

The SmartShunt is an all in one battery monitor without the display. Built in Bluetooth for ease of programming and monitoring

Download the Victron Bluetooth app:

  • Customize settings
  • Monitor all important data on a single screen
  • View the history
  • update the software when new features become available

Differences compared to BMV712 Battery Monitor:

  • No programmable visual and audible alarm.
  • No programmable relay

Details

  • Supply voltage range 6,5 - 70 VDC
  • Current draw 1mA
  • Input voltage range, auxiliary battery 6,5 - 70 VDC
  • Battery capacity (Ah) 1 - 9999 Ah
  • Operating temperature range -40 +50°C (-40 - 120°F)
  • Measures voltage of second battery, or temperature, or midpoint Yes
  • Temperature measurement range -20 +50°C
  • VE.Direct communication port Yes

Resolution and Accuracy

  • Current ± 0,01A
  • Voltage ± 0,01V
  • Amp hours ± 0,1 Ah
  • State of charge (0 – 100%) ± 0,1%
  • Time to go ± 1 min
  • Temperature (if optional temperature sensor connected) ± 1°C/°F (0 - 50°C or 30 - 120°F)
  • Accuracy of current measurement ± 0,4% Offset Less than 20 / 40 / 80 mA Accuracy of voltage measurement ± 0,3%

Dimensions

(h x w x d) 500A: 46 x 120 x 54 mm

Protection category IP21

Standards

Safety EN 60335-1 Emission / Immunity EN-IEC 61000-6-1 EN-IEC 61000-6-2 EN-IEC 61000-6-3 Automotive EN 50498

Cables

Two cables with 1A fuse, for ‘+’ connection and starter battery or midpoint connection

Optional

Temperature sensor (ASS000100000)
